6205-2RS Deep Groove Ball Bearing 25x52x15mm – Double Sealed

6205-2RS Deep Groove Ball Bearing – Premium Sealed Bearing for Industrial Applications

The 6205-2RS deep groove ball bearing is engineered for durability and high-speed performance in demanding industrial environments. Featuring double rubber seals (both sides), this sealed bearing delivers exceptional protection against contaminants while maintaining smooth, reliable rotation.

6205-2RS Bearing Specifications

• Bore Diameter (Inner): 25mm
• Outer Diameter: 52mm
• Width/Thickness: 15mm
• Seal Type: 2RS (double rubber seals, both sides)
• Material: Chrome steel (GCR15)
• Operating Temperature: -20°C to +100°C
• Dynamic Load Rating: 14.0 kN
• Static Load Rating: 7.8 kN
• Max Speed: 12,000 RPM

Applications

The 6205-2RS sealed bearing is widely used across multiple industries:

• Electric Motors: Ideal for motor shafts requiring reliable sealed protection
• Water Pumps: Withstands moisture and particle ingress
• Fans & Blowers: High-speed capability with contamination protection
• Conveyors: Handles radial and axial loads in material handling
• Agricultural Machinery: Dust and debris resistance for field equipment
• Power Tools: Consistent performance under variable loads

Why Choose DHJ 6205-2RS Bearing?

• Double Rubber Seals (2RS): Both sides factory-sealed for maximum contaminant protection
• High-Speed Performance: Precision machined raceways for smooth operation
• Pre-Lubricated: Ready to install, no additional lubrication required
• Excellent Load Capacity: Handles both radial and axial loads effectively
• ISO Certified: Manufactured to international quality standards

6205-2RS Interchange & Cross Reference

The 6205-2RS is interchangeable with standard 6205 series bearings from major brands including SKF 6205-2RS, FAG 6205-2RS, and NSK 6205DD. Commonly used as motor bearing, pump bearing, fan bearing, and conveyor bearing in industrial applications.
