Cylindrical Roller Bearing NU205

High-capacity cylindrical roller bearing with maximum radial load capability. Ideal for gearboxes, electric motors, and compressors. Features efficient load distribution and high-speed performance.

Why Choose DHJ NU205 Cylindrical Roller Bearing?

• Separable design — outer ring and roller-cage assembly can be mounted independently
• NU-type (one-sideflanged outer ring) allows for thermal expansion and precise location
• High radial load capacity with minimal friction — ideal for high-speed machinery
• Standard dimensions: interchangeable with SKF NU205, FAG NU205, NSK NU205
• Two retained ribs on inner ring, one free-floating rib on outer ring

Specifications

• Bore Diameter (d): 25 mm
• Outer Diameter (D): 52 mm
• Width (B): 15 mm
• Dynamic Load Rating: 18.2 kN
• Static Load Rating: 14.8 kN
• Max Speed: 14,000 RPM (oil lubrication)

Application range: Electric motors, pumps, compressors, gearboxes, printing machinery, textile machines. Wholesale pricing for bulk orders. Contact us for technical consultation.
